Dahua L Series

User's Manual
200
The following figure is for reference only.
Figure 4-98
Table 4-28
No. Function Description
1 Display Window
Display the searched recorded video or picture. It supports
playing in single-channel, 4-channel, 9-channel, and 16-
channel simultaneously.
When playing back in a single channel mode, hold down
the left mouse button to select the area that you want to
enlarge. The area is enlarged after the left mouse button is
released. To exit the enlarged status, right-click on the
image.
2
Playback Controls Bar
Playback control buttons. Refer to "4.6.2.1 Playback Control"
for detailed information.
Clip
Click to edit the record file and then save specified
footages. Refer to "4.6.2.3 Clip" for detailed information.
Backup
Click to backup record. Refer to "4.6.2.4 Record Backup"
for detailed information.
