Dahua XVR5116HS User Manual

95
Model
Parameters
HCVR5804S-V2
HCVR5808S-V2
HCVR5816S-V2
Video Output
1-ch VGA output,
1-ch HDMI output,
1-ch TV output,
HDMI/ VGA/TV video output at the same time (VGA/HDMI/TV of the
same video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch,BNC port, audio via
coaxial cable
8-ch,BNC port,
audio via coaxial
cable
16-ch,BNC port,
audio via coaxial
cable
Audio Output
1-ch,RCA port
Bidirectional
Talk Input
Support（Independent bidirectional talk port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
Alarm Output
6-ch alarm output
HDD
HDD Port
8 SATA ports,does not support eSATA port
Space/HDD
4T
Communication
Port
Network
2 RJ45 ports, 1000Mbps Ethernet port
Communication
1 RS232 port, 1 RS422 port, 1 RS485 port
USB
3 USB ports (One at the front panel and two at the rear panel)
Other
Power
AC90~264V 50+2% Hz (Max 220W)
Power
Consumption
≤35W（exclude HDD）
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
2U case,440mm（W）×460mm（D）×89mm（H）
Weight
7.0kg～8.0kg（exclude HDD）
Installation
Mode
Desk/rack installation
1.3.53 HCVR71XXH-4M Series
Model
Parameters
HCVR7104H-4M
HCVR7108H-4M
HCVR7116H-4M
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264+/H.264

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
