Dahua XVR5116HS User Manual

608
Figure 5- 164
Please refer to the following sheet for detailed information.
SN
Name
Function
1
Display
pan
 It is to display human face detection file list. The latest file is at the
top. \
 Click Export, you can export the selected file to the USB device.
There are two types: image/record.
 Image: Export the recognized human face image.
 Record: Export the record file before and after 10 seconds
when the DVR recognizes the human face.
2
Playback
pane
Play the searched record file or image. Double click to playback in full
screen.
3
Search
pane
Set date, start time and end time, click Search button, you can view the
corresponding file list.
5.14 Alarm
Click alarm function, you can see an interface is shown as Figure 5- 165.
Here you can set device alarm type and alarm sound setup (Please make sure you have
enabled audio function of corresponding alarm events.).

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
