Dahua XVR5116HS User Manual

347
4.4.12 Registration
Click , system goes to an interface for you to view remote device information. Please
refer to chapter 4.9.1.1.
4.4.13 Network
Click , system goes to the network interface. It is to set network IP address, default
gateway and etc. Please refer to chapter 4.9.2.
4.4.14 HDD Manager
Click , system goes to the HDD manager interface. It is to view and manage HDD
information. Please refer to chapter 4.9.4.2.
4.4.15 USB Manager
Click , system goes to the USB Manager interface. It is to view USB information,
backup and update. Please refer to chapter 4.7.3 Backup, chapter 4.8.4 Log, Chapter
4.9.5.12 Import/Export,, and chapter 4.9.5.14 Upgrade for detailed information.
4.5 USB Device Auto Pop-up
After you inserted the USB device, system can auto detect it and pop up the following
dialogue box. It allows you to conveniently backup file, log, configuration or update
system. See Figure 4-69. Please refer to chapter 4.7.3 Backup, chapter 4.8.4 Log,
Chapter 4.9.5.12 Import/Export,, and chapter 4.9.5.14 Upgrade for detailed information.
Figure 4- 69

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
