Dahua XVR5116HS User Manual

138
1.3.74 XVR74XXL Series
Alarm Output
6-channel
HDD
HDD Port
4 SATA ports. Support eSATA port.
Space/HDD
8T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS232 port, 1 RS422 port, 1 RS485 port
USB
3 USB ports(One at
the front panel and
two at the rear
panel)
3 USB ports (One at the front panel and two
at the rear panel. The rear panel supports
USB3.0)
Other
Power
AC100-240V 1.9A 50/60Hz
Power
Consumption
（No HDD）
30W (No HDD)
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1.5U case,440mm（W）×410mm（D）×70mm（H）
Weight
（No HDD）
≤7KG (No HDD)
≤7.2KG (No HDD)
≤7.5KG (No HDD)
Installation
Mode
Desk installation
Model
Parameters
XVR7408L
XVR7416L
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264H, H.264, H.264B
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF/
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps～6144Kbps
( For 720P:default value is 2Mbps,max value is 4Mbps.
For 1080P:default value is 4Mbps,max value is 6Mbps)
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz,16Bit

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
