Dahua XVR5116HS User Manual

574
Figure 5- 111
Step 4 Click Save to complete the setup.
5.10.4.7 Quota
It is to set channel storage capacity.
CAUTION
HDD group and quota mode cannot be valid at the same time. System needs to restart
once you change the mode here.
Step 1 From main menu->Setup->Storage->Quota.
Enter quota interface. See Figure 5- 112.
Figure 5- 112
Step 2 Select a channel from the dropdown list and then select corresponding HDD
quota.
Step 3 Click Apply or Save to complete setup.
Step 4 Click Statistics to view HDD capacity you set for each channel.
5.10.5 Setting
5.10.5.1 General
The general interface includes general, date/time and holiday setup.
5.10.5.1.1 General
The general interface is shown as in Figure 5- 113.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
