Dahua XVR5116HS User Manual

599
e) System only checks start address if you add IP address. System check start
address and end address if you add IP section and the end address shall be
larger than the start address.
f) System may check newly added IP address exists or not. System does not add if
input IP address does not exist.

Delete: Click it to remove specified item.

Edit: Click it to edit start address and end address. See Figure 5- 149. System can
check the IP address validity after the edit operation and implement IPv6 optimization.

Default: Click it to restore default setup. In this case, the trusted sites and blocked
sites are both null.
Step 4 Click Save to complete setup.

If you enabled trusted sites, only the IP in the trusted sites list can access the
device.

If you enabled blocked sites, the IP in the blocked sites cannot access the
device.
Figure 5- 148
Figure 5- 149
5.11 Information
5.11.1 Version
Here you can view record channel, alarm input/output information, software version,
release date and etc.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
