Dahua XVR5116HS User Manual

15
Parameters
HCVR2108C-S2
Mode
1.3.8 HCVR410XC-S3 Series
Parameters
HCVR4104C-S3
HCVR4108C-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080N/720P/960H/D1/HD1/2CIF/CIF
1080N@12f/720P(Non
realtime)/960H/D1/HD1/2C
IF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-4096Kbps,
For 720P: default setup is 1.5Mbps,max supports 4Mbps.
For 1080P: default setup is 1.5Mbps,max supports 4Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port(HDCVI HD
video/general standard definition
video self-adaptive)
8-ch BNC port(HDCVI HD
video/general standard
definition video self-adaptive)
Network Video
Input
 Max add 1 IP channel
connection
 Analog/digital channel switch.
Max 5 IP channel
connections
 Connection
bandwidth:4Mbps-20Mbps
 Max add 2 IP channel
connections
 Analog/digital channel
switch. Max 10 IP channel
connections
 Connection
bandwidth:8Mbps-56Mbp
s
Video Output
1-channel VGA output,
1-channel HDMI output (of the same video source),
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
4-ch
8-ch

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
