Dahua XVR5116HS User Manual

45
Parameters
HCVR7104H-S2
HCVR7108H-S2
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case,325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
1.3.24 HCVR710XHE-S2 Series
Parameters
HCVR7104HE-S2
HCVR7108HE-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI:1～25f/s（PAL）; 1~30f/s（NTSC）
CVBS:1~25f/s（PAL）; 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-6144Kbps,
For 1080P: default setup is 4Mbps,max supports 6Mbps.
For 720P: default setup is 2Mbps,max supports 4Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
