Dahua XVR5116HS User Manual

60
Parameters
2104HS-S3
2108HS-S3
2116HS-S3
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port of the 1st channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×44mm（H）
Weight （ No
HDD）
≤1.25KG
≤1.35KG
≤1.45KG
Installation
Mode
Desk
1.3.33 HCVR41XXHS-S3 Series
Parameters
HCVR4104HS-S3
HCVR4108HS-S3
HCVR4116HS-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080N/720P/960H/D1
/HD1/2CIF/CIF/
1080N@12f/720P@15f/960H/D1/HD1/2CI
F/CIF/
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-4096Kbps,
For 720P: default setup is 1.5Mbps,max supports 4Mbps.
For 1080P: default setup is 1.5Mbps,max supports 4Mbps.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
