Page #357 background image
341
In Figure 4- 56, input tour value and then click to call a tour. Click again
to stop call.
Call Scan
In Figure 4- 56, input Scan value and then click to call a tour. Click again
to stop call.
Rotate
In Figure 4- 56, click to enable the camera to rotate.
System supports preset, tour, pattern, scan, rotate, light and etc function.
Note
Preset, tour and pattern all need the value to be the control parameters. You can
define it as you require.
You need to refer to your camera users manual for Aux definition. In some cases, it
can be used for special process.
Aux
Click , system goes to the following interface. The options here are defined by the
protocol. The aux number is corresponding to the aux on-off button of the decoder. See
Figure 4- 62.
Figure 4- 62
4.3.4 Auto Focus
Note
This function is for the motorized-lens network camera.
For HD auto focus camera, you can go to the PTZ control interface to set. Please
refer to Chapter 4.3.3 PTZ.
On the preview interface, right click mouse and then select Auto focus, you can go to the
following interface. See Figure 4- 63.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua XVR5116HS and is the answer not in the manual?

Dahua XVR5116HS Specifications

General IconGeneral
USB Interface2 USB 2.0 ports
Power SupplyDC 12V/2A
Video Output1 HDMI, 1 VGA
Operating SystemEmbedded Linux
Video CompressionH.264+/H.264
Analog Camera Input16 channel, BNC
IP Camera InputUp to 16 channels
Audio In/Out1/1, RCA
Display Resolution1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface1 RJ-45 Port (10/100 Mbps)
HDD1 SATA port, up to 6 TB
Dimensions260 mm × 238 mm × 48 mm (W × D × H)
Smart FunctionsSMD Plus
VGA Output1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature-10°C to +55°C
Operating Humidity10%–90% (RH), non-condensing
