Parameters
HCVR5104HS-S3
HCVR5108HS-S3
HCVR5116HS-S3
Port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤7W
≤8W
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×44mm（H）
Weight (No
HDD)
≤0.85KG
≤0.95KG
≤1.05KG
Installation
Mode
Desk
1.3.35 HCVR71XXHS-S3 Series
Parameters
HCVR7104HS-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-6144Kbps,
For 720P: default setup is 2Mbps,max supports 4Mbps.
For 1080P: default setup is 4Mbps,max supports 6Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port(HDCVI HD video/general standard definition video
self-adaptive)
Network Video
Input
 Max add 2 IP channel connections
 Analog/digital channel switch. Max 6 IP channel connections
 Connection bandwidth:8Mbps-24Mbps
Video Output
1-channel VGA output,

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
