Dahua XVR5116HS User Manual

111
Parameters
XVR7104HE
XVR7108HE
XVR7116HE
One HDD Space
6T
Communication
Port
Network
1 RJ45 port,
100Mbps Ethernet
port
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One
at the front panel and
one at the rear panel)
1 USB2.0 port and 1 USB3.0 port (One
USB2.0 port at the front panel and one
USB3.0 port at the rear panel)
Others
Power
DC12V
Power
Consumption
≤8W
≤10W
≤15W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case,325mm（W）×245mm（D）×45mm（H）
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk
1.3.62 XVR71XXH Series
Parameters
XVR7104H
XVR7108H
XVR7116H
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-6144Kbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(CVBS/CVI/AHD
/other analog HD
video self-adaptive)
8-ch BNC
port(CVBS/CVI/AHD
/other analog HD
video self-adaptive)
16-ch BNC
port(CVBS/CVI/A
HD /other analog
HD video

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
