Dahua XVR5116HS User Manual

575
Figure 5- 113
Please refer to the following sheet for detailed information.
Parameter
Function
Device ID
It is to set device name.
Device No.
It is device channel number.
Language
You can select the language from the dropdown list.
Please note the device needs to reboot to get the modification
activated.
Video Standard
This is to display video standard such as PAL.
Auto logout
Here is for you to set auto logout interval once login user remains inactive
for a specified time. Value ranges from 0 to 60 minutes.
IPC Time Sync
You can input an interval here to synchronize the DVR time and IPC time.
Navigation bar
Check the box here, system displays the navigation bar on the interface.
5.10.5.1.2 Date and time
The date and time interface is shown as in Figure 5- 114.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
