Dahua XVR5116HS User Manual

164
Parameters
XVR4104HS-S2
XVR4108HS-S2
XVR4116HS-S2
Parameters
Standard
Encode
Resolution
1080N/720P/960H/D1
/HD1/2CIF/CIF/
1080N@12fps/720P@15fps/960H/D1/HD1
/2CIF/CIF/
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-4096Kbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM/AAC (AAC for the first channel only)
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(CVBS/CVI/AHD
/other analog HD
video self-adaptive)
8-ch BNC
port(CVBS/CVI/AHD
/other analog HD
video self-adaptive)
16-ch BNC
port(CVBS/CVI/A
HD /other analog
HD video
self-adaptive)
Network Video
Input

There is no IP
channel by
default. Max add
1 IP channel
connection

Analog
/digital channel
switch. Max 5 IP
channel
connections

Connection
bandwidth:0Mbp
s-20Mbps

There is no IP
channel by
default. Max add
2 IP channel
connections.

Analog
/digital channel
switch. Max 10 IP
channel
connections

Connection
bandwidth:0Mbp
s-40Mbps

There is no IP
channel by
default. Max
add 2 IP
channel
connections

Analog
/digital
channel
switch. Max
18 IP channel
connections

Connection
bandwidth:0
Mbps-56Mbp
s
Video Output
1-channel VGA output,
1-channel HDMI output (of the same video source),
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
4-channel
8-channel
16-channel

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
