Dahua XVR5116HS User Manual

171
Parameters
XVR5104HE-S2
XVR5108HE-S2
XVR5116HE-S2
Audio Port
Audio Input
4-channel RCA port.
8-channel RCA port.
16-channel RCA
port.
Coaxial Audio
Input
4-channel
8-channel
16-channel
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Playback
Channel
4-channel
8-channel
16-channel
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
8-channel input
8-channel input
16-channel input
Alarm Output
3-channel output
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
8T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
1 RJ45 port,
1000Mbps
Ethernet port
RS85
Communication
1 RS485 port
USB
2 USB2.0 ports(One at the front panel and one
at the rear panel)
1 USB2.0 port
and 1 USB3.0
port (One
USB2.0 port at
the front panel
and one USB3.0
port at the rear
panel)
Others
Power
DC12V
Power
Consumption
≤7W
≤8W
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case,325mm（W）×245mm（D）×45mm（H）
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
