Dahua XVR5116HS User Manual

321
Figure 4- 34
Step 2 Select the import file and then click the OK button.
System pops up a dialogue box to remind you successfully exported.
Note
If the imported IP has conflicted with current added device, system pops up a
dialogue box to remind you. You have two options:

OK: Click OK button, system uses the imported setup to overlay current one.

Cancel: Click Cancel button, system adds the new IP setup.
Step 3 Please click OK button to exit.
WARNING

You can edit the exported .CSV file. Do not change the file format; otherwise it
may result in import failure.

Does not support customized protocol import and export.

The import and export device shall have the same language format.
4.1.4.5 Encode
It is to set video bit streams, image bit streams, and video overlay parameters.
Besides startup wizard and configuration wizard, from main
menu->Setting->Camera->Encode, you can also go to the following interface.
4.1.4.5.1Encode
Step 1 Click Encode tab.
Enter Encode interface. See Figure 4- 35.
Step 2 Set parameters.

Channel: Select the channel you want.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
