Dahua XVR5116HS User Manual

401
Figure 4- 130
Here you can set a multiple cast group. Please refer to the following sheet for detailed
information.

IP multiple cast group address
-224.0.0.0-239.255.255.255
-“D” address space

The higher four-bit of the first byte=”1110”

Reserved local multiple cast group address
-224.0.0.0-224.0.0.255
-TTL=1 When sending out telegraph
-For example
224.0.0.1 All systems in the sub-net
224.0.0.2 All routers in the sub-net
224.0.0.4 DVMRP router
224.0.0.5 OSPF router
224.0.0.13 PIMv2 router

Administrative scoped addressees
-239.0.0.0-239.255.255.255
-Private address space

Like the single broadcast address of RFC1918

Cannot be used in Internet transmission

Used for multiple cast broadcast in limited space.
Except the above mentioned addresses of special meaning, you can use other addresses.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
