Dahua XVR5116HS User Manual

423
2. Set parameters.

Name: Input customized rule name.

Period: System can generate an alarm once the object is in the zone for
the specified period.
 Target filter: Click , you can set filter object size. Each rule can set
two sizes (min size/max size). Once the object is smaller than the min
size or larger than the max size, there is no alarm. Please make sure
the max size is larger than the min size.
3. Left click mouse to draw a zone, until you draw a rectangle, you can right
click mouse.
4. Click OK.
Complete drawing abandoned object detection rule.
Step 3 Click , it is to set parameters.
Please refer to chapter 4.9.3.3 to set other parameters.
Step 4 Check the Enable box to enable abandoned object detection function. Click
Apply or Save to complete setup.
Device begins abandoned object detection.
4.9.3.6 Missing Object Detection (Optional)
System generates an alarm when there is missing object in the specified zone.

System supports customized area shape and amount.

Support duration setup.

Support objects filter function.
Step 1 From main menu->Setting->Event->IVS, select the type as abandoned object,
the object interface is shown as below. See Figure 4- 153.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
