Dahua XVR5116HS User Manual

453
Tips
You can check All button after the corresponding status to enable/disable all-channel
snapshot function.
Click Apply or Save to complete setup.
4.9.4.6 Quota
It is to set channel storage capacity.
CAUTION

This function is for some series only.

HDD group and quota mode cannot be valid at the same time.

System needs to restart once you change the mode here.
Step 1 From main menu->Setting->Storage->Quota.
Enter quota interface. See Figure 4- 191.
Figure 4- 191
Step 2 Select a channel from the dropdown list and then select corresponding HDD
quota.
Step 3 Click Apply or Save to complete setup.
Step 4 Click Statistics to view HDD capacity you set for each channel. See Figure
4- 192.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
