Dahua XVR5116HS User Manual

523
5.10.2.3.1 Create Server Certificate
If it is your first time to use this function, please follow the steps listed below.
In Figure 5- 43, click button, input country name, state name
and etc. Click Create button. See Figure 5- 44.
Note
Please make sure the IP or domain information is the same as your device IP or domain
name.
Figure 5- 44
You can see the corresponding prompt. See Figure 5- 45. Now the server certificate is
successfully created.
Figure 5- 45
5.10.2.3.2 Download root certificate
In Figure 5- 43, click button, system pops up a dialogue box.
See Figure 5- 46.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
