Dahua XVR5116HS User Manual

530
This function is for some series products only.
Use PPPoE(Point-to-Point Protocol over Ethernet) to establish network connection.
Device can get a dynamic IP address in the WAN. Before the operation, please contact
your ISP (Internet service provider) for PPPoE user name and password.
Step 1 From main window->Setup->Network->PPPoE.
Enter PPPoE interface. See Figure 5- 57.
Figure 5- 57
Step 2 Check the box to enable PPPoE function and input the PPPoE user name and
password.
Step 3 Click Save to complete the setup.
Step 4 Device connects to the internet via PPPoE. You can get the IP address in the
WAN from the IP address column.
Note
After enable PPPoE function, the IP address on the TCP/IP
(Setup->Network->TCP/IP) interface is read-only.
5.10.2.7 DDNS
The DDNS interface is shown as in Figure 5- 58.
The DDNS is to set to connect the various servers so that you can access the system via
the server. Please go to the corresponding service website to apply a domain name and
then access the system via the domain. It works even your IP address has changed.
Please select DDNS from the dropdown list (Multiple choices). Before you use this
function, please make sure your purchased device support current function.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
