Dahua XVR5116HS User Manual

535
Parameter
Function
Port mapping list
It is the same information on the UPnP list of the router.
 Service name:Defined by user.
 Protocol: Protocol type
 Internal port:Port that has been mapped in the router.
 External port:Port that has been mapped locally.
Note
 When you are setting the router external port, please use
1024~5000 port. Do not use well-known port 1~255 and the
system port 256~1023 to avoid conflict.
 When there are several devices in the same LAN, please arrange
the port mapping properly in case several devices are mapping to
the same external port.
 Please make sure the mapping port is available.
 For the TCP and UDP, please make sure the internal port and
external port are the same to guarantee the proper data
transmission.
Modify
Click ,you can change WAN port value.
Figure 5- 61
5.10.2.11 SNMP
Note
This function is for some series products only.
SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic
network management frame of the network management system. The SNMP widely used
in many environments. It is used in many network device, software and system.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
