5.10.2.12 Multicast
The multicast interface is shown as in Figure 5- 63.
Multicast is a transmission mode of data packet. When there is multiple-host to receive
the same data packet, multiple-cast is the best option to reduce the broad width and the
CPU load. The source host can just send out one data to transit. This function also
depends on the relationship of the group member and group of the outer.
Parameter
Function
IP address
The multicast IP address (0.0.0.0～255.255.255.255).
Port
The multicast port value(1025～65000).
Figure 5- 63
Click Save to complete the setup. Login and monitor.
Use WEB to login, you can see the following interface. See Figure 5- 64. Select login type
as the Multicast from the dropdown list. After you logged in the Web, the Web can
automatically get multiple cast address and add it to the multiple cast groups. You can
enable real-time monitor function to view the video.
Figure 5- 64
5.10.2.13 Auto Register
The auto register interface is shown as below. See Figure 5- 65.
This function allows the device to auto register to the proxy you specified. In this way, you
can use the client-end to access the DVR and etc via the proxy. Here the proxy has a
switch function. In the network service, device supports the server address of IPv4 or
domain.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
