Dahua XVR5116HS User Manual

542
Figure 5- 71
Figure 5- 72
Please refer to the following sheet for detailed information.
Parameter
Function
Enable MD
You need to check the box to enable motion detection function.
Please select a channel from the dropdown list.
Enable PIR
PIR function help enhance the motion detect accuracy and validity.
It is to filter the false alarm triggered by leaves, small fly and
insects. The PIR detection zone is smaller than the camera angle
of view.
The PIR function is enabled by default if the connected remote
device supports the PIR function. When the PIR function is on,
motion detection function is on by default. The motion detect event

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
