Dahua XVR5116HS User Manual

567
Step 2 Set parameters.
Parameter
Function
HDD full
It is to select working mode when hard disk is full. There are two options:
stop recording or rewrite.
 Stop: If current HDD is full while there is no idle HDD, then system
stops recording,
 Overwrite: If the current HDD is full while there is no idle HDD, then
system overwrites the previous files.
Note
DVR does not overwrite the locked files.
Pack
duration
It is to specify record duration. There are two ways for you to set.
 Time length: It is to pack according to time. The value ranges from 1
to 60 minutes. Default value is 60 minutes.
 File length: It is to pack according to file length. The default setup is
1024M. The value ranges from 128M to 2048M.
Auto
delete old
files

Never: Do not auto delete old files.
 Customized: input customized period here, system can auto delete
corresponding old files
5.10.4.2 Schedule
5.10.4.2.1 Schedule Record
In this interfaces, you can add or remove the schedule record setup. See Figure 5- 101.
There are three record modes: general (auto), motion detect and alarm. There are six
periods in one day.
You can view the current time period setup from the color bar.

Green color stands for the general record/snapshot.

Yellow color stands for the motion detect record/snapshot..

Red color stands for the alarm record/snapshot.

Blue color stands for MD&alarm record/snapshot.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
