Dahua XVR5116HS User Manual

577
Parameter
Function
Port
It is to set the time server port.
Interval
It is to set the sync periods between the device and the time server.
5.10.5.1.3 Holiday Setup
Holiday setup interface is shown as in Figure 5- 115.
Here you can click Add box to add a new holiday and then click Save button to save.
Note
Once the holiday settings is different the general date, the holiday settings has priority.
After successfully set holiday here, you can view holiday item in Schedule interface. It is
for you to set holiday schedule record/snapshot settings.
Figure 5- 115
5.10.5.2 Display
Display interface includes GUI, TV adjust, Tour and zero-channel encoding.
5.10.5.2.1 Display
Here you can set background color and transparency level. See Figure 5- 116.
Figure 5- 116

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
