Dahua XVR5116HS User Manual

581
Figure 5- 120
Please refer to the following sheet for detailed information.
Parameter
Function
Enable
Check the box here to enable this function.
Interval
It is to set the interval from current channel group to the next
channel group.
Window split
Support 1-window split only.
Delete
Select a channel group and then click to delete it.
Up/Down
Click or to adjust channel tour sequence.
Add channel group
Click ,you can see system pops up the following dialogue box. See Figure 5- 121.
Please select the channels and then click OK button.
Figure 5- 121
Delete channel group

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
