Dahua XVR5116HS User Manual

590
Figure 5- 135

Click Setting to set the periods. Or you can draw on the interface directly.
There are six periods in one day. Or you can input start time and end time
directly.

Check the box before the date, the settings are for the selected date(s).

Check the box before the period1-6, it is to enable the period function.
Step 4 Click Save to complete the setup.
Note
Please note the user rights shall not exceed the group right setup. For
convenient setup, please make sure the general user has the lower rights setup
than the admin.
Modify user
It is to modify the user property, belonging group, password and rights. See Figure 5- 136.

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
