Dahua XVR5116HS User Manual

75
Model
Parameters
HCVR4204A-S3
HCVR4208A-S3
HCVR4216A-S3
Network Video
Input
 Max add 1 IP
channel
connection
 Analog
/digital channel
switch. Max 5 IP
channel
connections
 Connection
bandwidth:4Mbps-
20Mbps
 Max add 2 IP
channel
connections
 Analog
/digital channel
switch. Max 10 IP
channel
connections
 Connection
bandwidth:8Mbps-
40Mbps
 Max add 2
IP channel
connectio
ns
 Analog
/digital
channel
switch.
Max 18 IP
channel
connectio
ns
 Connectio
n
bandwidth
:8Mbps-56
Mbps
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
External
Audio Input
4-ch,RCA port,
Coaxial Audio
Input
4-ch
8-ch
16-ch
Audio Output
1-ch RCA port
Bidirectional
Talk Input
Support（Reuse the audio port of the 1
st
channel）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm
input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
6T
Communication
Network
1 RJ45 port, 100Mbps Ethernet port

Dahua XVR5116HS Specifications

General

USB Interface	2 USB 2.0 ports
Power Supply	DC 12V/2A
Video Output	1 HDMI, 1 VGA
Operating System	Embedded Linux
Video Compression	H.264+/H.264
Analog Camera Input	16 channel, BNC
IP Camera Input	Up to 16 channels
Audio In/Out	1/1, RCA
Display Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Network Interface	1 RJ-45 Port (10/100 Mbps)
HDD	1 SATA port, up to 6 TB
Dimensions	260 mm × 238 mm × 48 mm (W × D × H)
Smart Functions	SMD Plus
VGA Output	1920 × 1080, 1280 × 1024, 1280 × 720
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–90% (RH), non-condensing
