18 Technical Data
The following basic technical data was valid at the time of this document’s compilation.
Detailed specications and possible updates for each device can be found in the corre-
sponding current product data sheet on www.dallmeier.com.
The following specications are valid for all devices described in this document, unless
otherwise indicated.
Specications
Sensor 1/2.5" 5-megapixel CMOS image sensor
with Dallmeier
technology
Lens mount CS-mount
Auto iris control Compatible with DC drive auto iris lenses
Video output 1× BNC:
CVBS, analogue SD video preview output,
for local installation only
Audio OUT / Microphone IN
(each mono signal) 1× 3.5 mm phone jack (for stereo plug)
7)
Microphone IN:
max. 63 mV (RMS),
input resistance 10 kOhm,
internal gain 20 dB
Ethernet 1× RJ45 jack, 10BASE-T/100BASE-TX PoE
Voltage supply 12 V DC ±10% or via PoE (Class 0)
PoE standard IEEE 802.3af
Power consumption Max. 4.5 W
Dimensions box cameras (w/o lens) Approx.
W 71 × H 66 × L 118 mm
(W 2.8 × H 2.6 × L 4.6 inches)
Dimensions dome cameras In-ceiling mount variants:
approx. Ø 170 × H 135 mm (Ø 6.7 × H 5.3 inches)
Surface mount variants:
approx. Ø 153 × H 135 mm (Ø 6.0 × H 5.3 inches)
Weight box cameras (w/o lens) Approx. 300 g (0.7 lb)
Weight dome cameras In-ceiling mount variants:
approx. 1200 g (2.6 lb)
Surface mount variants:
approx. 1100 g (2.4 lb)
Mechanical adjustment 3-axis (dome cameras only)
Operating temperature box cameras −10 °C to +45 °C (14 °F to 113 °F)
Operating temperature dome cameras In-ceiling mount variants (indoor):
0 °C to +35 °C (32 °F to 95 °F)
Surface mount variants (indoor and outdoor):
−10 °C to +40 °C (14 °F to 104 °F)
Relative humidity 0 % – 90 % RH, non-condensing
IP rating IP67 (dome cameras surface mount variants only)
IK code
8)
(dome cameras only) IK10 (EN 62262, IEC 62262:2002)
Approvals/certications CE, FCC, ACA, UVV-Kassen (DGUV Test),
DIN EN 50130-4 compliant
7) Audio IN/OUT Y-Cable Connector FGA-30 required (optionally available)
8) Protection against external mechanical impacts
