dallmeier DF4910HD-DN - Surface Mount Variant (SM)

DF4910HD-DN | DDF4910HDV-DN-IM/-SM
www.dallmeier.com 19
5.2.2 Surface Mount Variant (SM)
Thread for
PG16 cable gland
Mounting hole for
Ø 4 mm screw
Housing base
Housing with bubble
Lens
3-axis mount
(pan / tilt / rotation)
Housing screw
(T20 Torx)
Black inner
dome cover
Ambient light sensor
Removable foam ring
Fig. 5-5
NOTICE
Always ensure that the lens and the ambient light sensor are not covered
by the black inner dome cover when assembling the camera enclosure.
