Dalsa Linea SWIR GigE Series User Manual

8
•
Linea SWIR GigE Series Overview Linea SWIR GigE Series Camera
Linea SWIR GigE Application Advantages
• Compact form factor.
• Optimized, rugged design.
• GigE Vision 1.2 compliant.
• Gigabit Ethernet (GigE) connection to a computer via standard CAT5e or CAT6 cables.
• Supports connection to the host computer NIC through a GigE network switch.
• 8-bit or 12-bit output.
• High line rates.
• Configurable full well.
• 2 general-purpose inputs with programmable threshold.
• 2 general-purpose outputs.
• Visual status LED on camera back plate.
• Supported by Sapera™ LT software libraries.
• Camera power via a 10-pin GPIO connector or Power over Ethernet (PoE).
• Digital binning for increased sensitivity.
• 4 User Settings sets for camera configuration storage.
Linea SWIR GigE Firmware
Teledyne DALSA’s Linea SWIR GigE camera firmware contains open source software. Information
about these open source licenses and documentation are available at www.teledynedalsa.com.
Firmware updates for Linea SWIR GigE are available for download from Teledyne DALSA’s web site
[http://www.teledynedalsa.com/imaging/support/downloads/firmware/]. Choose Linea SWIR GigE
Firmware from the available download section and update the camera using CamExpert (see File
Access via the CamExpert Tool (Quick Camera Firmware Upgrade)). Camera firmware is
upgradable or down gradable.
Part Numbers and Software Requirements
This manual covers the Linea SWIR GigE models summarized below. This manual is updated with
the release of new models. See Sensor Specifications for details of each Linea SWIR GigE model.
Camera Resolution Pixel size
Max. Line
Rate
Lens Mount
(treaded)
Product Number
Linea SWIR GigE 1K 1024 x 1
12.5 x 12.5 μm
40 kHz C-Mount SL-GA-01K04A-00-R
Linea SWIR GigE 512 512 x 1
25 x 25 μm
40 kHz C-Mount SL-GA-05H04A-00-R
Teledyne DALSA Software Platform
Sapera LT version 8.00 and later includes the Sapera Network Imaging
Package and GigE Vision Imaging Driver.
Sapera provides everything needed to develop imaging applications.
New or alternative Linea SWIR GigE Firmware Designs.
Available for download
http://www.teledynedalsa.com/imaging/support/
downloads/sdks/
Sapera Processing Imaging Development Library. Via web download
