Linea SWIR GigE Series Camera Linea SWIR GigE Series Overview
11
Camera Size 46 x 46 x 55 mm
For complete dimensions, refer to the Camera Mechanical Specifications section.
Mass <150 g (no lens)
Power Connector via 10-pin I/O connector, or RJ45 in PoE mode
Ethernet Connector RJ45
Electrical Interface
Input Voltage +12 to +24 Volt DC (+10 +/- 10 %) auxiliary connector
Supports the Power Over Ethernet standard (PoE Class 2 as per IEEE 802.3af)
Power Dissipation < 4 W
Output Data Configuration Gigabit Ethernet 1000 Mbps (10/100 Mbps are not supported) 115 MB/sec maximum
Data and Control GigE Vision 1.2 compliant
Environmental Specifications
Storage Temperature Range -20 °C to +70 °C
Humidity (operation and
storage)
15 % to 85 % relative, non-condensing
Operating Temperature 0 °C to 50 °C range at front plate
Test Conditions
• Values measured using 12-bit, 1x Digital gain, Maximum sensor gain
• Light source: 1050 nm
• Front plate temperature: 45 °C
