Dalsa Linea SWIR GigE Series User Manual

Linea SWIR GigE Series Camera Operational Reference
•
47
Counter Duration counterDuration Sets the duration (or number of events) before the
CounterEnd event is generated.
1.00
Expert
DFNC
Counter Value counterValue Read the current value of the selected counter.
(RO)
1.00
Expert
DFNC
Counter Value At Reset counterValueAtReset Reads the value of the selected counter when it
was reset by a trigger or by an explicit Counter
Reset command. (RO)
1.00
Expert
DFNC
Counter Reset counterReset Resets the selected counter to zero. The counter
starts immediately after the reset. To temporarily
disable the counter, set the Counter Event Source
feature to Off. (WO)
1.00
Expert
DFNC
Timer Selector timerSelector Selects which timer to configure. 1.00
Expert
DFNC
Timer 1 Timer1 Configure Timer 1.
Timer Mode timerMode Select the timer mode. The selected Timer is Active
or Disabled. When Disabled, the Timer can be
configured.
1.00
Expert
DFNC
Off Off The selected Timer is Disabled.
Active Active The selected Timer is Enabled.
Timer Status timerStatus Returns the current state of the timer. (RO) 1.00
Expert
DFNC
Timer Idle TimerIdle The timer is idle. The CounterStartSource feature is
set to off.
Timer Trigger Wait TimerTriggerWait The timer is waiting for a start trigger.
Timer Delaying TimerDelaying The timer is counting the requested delay.
Timer Active TimerActive The timer is counting for the specified duration.
Timer Completed TimerCompleted The timer reached the TimerDuration count.
TimerStartSource timerStartSource Select the trigger source to start the timer. The
Event Control section provides details and timing
diagrams for the supported events.
1.00
Expert
DFNC
TimerReset Cmd Off Start on reception of the TimerReset Icommand.
Acquisition Start AcquisitionStart Start Timer on Acquisition Start event.
Exposure Start ExposureStart Start Timer on Exposure Start event.
Frame Start FrameStart Start Timer on Frame Start event.
Line 1 Line1 Start Timer on a transition of I/O Line 1 event.
Line 2 Line2 Start Timer on a transition of I/O Line 2 event.
Timer 1 End Timer1End Start Timer on Timer 1 End event.
Counter 1 End Counter1End Start Timer on Counter 1 End event.
Timer Line Activation timerStartLineActivation Select the trigger activation mode which starts the
timer.
1.00
Expert
DFNC
Rising Edge RisingEdge Starts counter on rising edge of the selected signal.
Falling Edge FallingEdge Starts counter on falling edge of the selected
signal.
Any Edge AnyEdge Starts counter on the falling or rising edge of the
selected signal.
Timer Delay timerDelay Sets the duration (in microseconds) of the delay to
apply at the reception of a trigger before starting
the timer.
1.00
Expert
DFNC
Timer Duration timerDuration Sets the duration (in microseconds) of the timer
pulse.
1.00
Expert
DFNC
Timer Value timerValue Reads the current value (in microseconds) of the
selected timer.
1.00
Expert
DFNC
