Dalsa Linea SWIR GigE Series User Manual

46
•
Operational Reference Linea SWIR GigE Series Camera
Rising Edge RisingEdge Starts counting on rising edge of the selected Line.
Falling Edge FallingEdge Starts counting on falling edge of the selected Line.
Any Edge AnyEdge Starts counting on the falling or rising edge of the
selected Line.
CounterIncremental
Source
counterIncrementalSource Select the event source which increments the
counter. The
Event Control section provides
details and timing diagrams for the supported
events.
1.00
Expert
DFNC
Off Off Counter is stopped.
Acquisition Start AcquisitionStart Counts the number of Acquisition Start events.
Exposure Start ExposureStart Counts the number of Exposure Start events.
Exposure End ExposureEnd Counts the number of Exposure End events.
Frame Start FrameStart Counts the number of Frame Start events.
Line 1 Line1 Counts the number of transitions on Line 1 (based
on the counterIncrementalLineActivation feature
setting)
Line 2 Line2 Counts the number of transitions on Line 2 (based
on the counterIncrementalLineActivation feature
setting)
Rotary Encoder rotaryEncoder1 The counter increments on rotary encoder ticks.
Internal Clock InternalClock The counter increments on each microsecond tick
of the device internal Clock.
Timer 1 End Timer1End Counts the number of Timer 1 End events.
Rejected Trigger InvalidTrigger Counts the number of invalid triggers.
Counter Incremental Line
Activation
counterIncrementalLineActivation Selects the counter signal activation mode for line
inputs. The counter increments on the specified
signal edge or level.
1.00
Expert
DFNC
Rising Edge RisingEdge Increment the counter on the rising edge of the
selected I/O Line.
Falling Edge FallingEdge Increment the counter on the falling edge of the
selected I/O Line.
Any Edge AnyEdge Increment the counter on the falling or rising edge
of the selected I/O Line.
Counter Reset Source counterResetSource Selects the signal source to reset the counter then
waits for the next countStartSource signal or
event.
1.00
Expert
DFNC
Reset Cmd Off Reset on reception of the Reset Icommand.
Acquisition Start AcquisitionStart Reset on reception of the Acquisition Start.
Acquisition End AcquisitionEnd Reset on reception of the Acquisition End.
Exposure Start ExposureStart Reset on reception of the Exposure Start event.
Exposure End ExposureEnd Reset on reception of the Exposure End event.
Line 1 Line1 Reset counter on the specified transition on line 1.
Line 2 Line2 Reset counter on the specified transition on line 2.
Timer 1 End Timer1End Reset on reception of the Timer 1 End.
Counter 1 End Counter1End Reset on the reception of the Counter 1 End.
Counter Reset Input Line
Activation
counterResetLineActivation Specify the edge transition on the selected line that
will reset the selected counter.
1.00
Expert
DFNC
Rising Edge RisingEdge Reset counter on rising edge of the selected signal.
Falling Edge FallingEdge Reset counter on falling edge of the selected
signal.
Any Edge AnyEdge Reset counter on the falling or rising edge of the
selected signal.
