Dalsa Linea SWIR GigE Series User Manual

Linea SWIR GigE Series Camera Operational Reference
•
45
Counter and Timer Control Feature Description
The following Counter and Timer Block Diagram describes the parameters along with their view
attributes and minimum camera firmware version required. The Device Version column indicates
which parameter is a member of the DALSA Features Naming Convention (indicated by DFNC),
versus the GenICam Standard Features Naming Convention (SFNC not shown).
The Device Version number represents the camera software functional group, not a firmware
revision number. As Linea SWIR GigE capabilities evolve the device version will increase,
identifying the supported function package. New features for a major device version release will be
indicated by green text for easy identification.
Display Name Feature & Values Description Device Version
& View
Counter Selector counterSelector Selects the counter to configure.
1.00
Expert
DFNC
Counter 1 Counter1 Select counter 1.
Counter Mode counterMode Selects the counter mode. The selected Counter is
either Active or Disabled. When Disabled, the
Counter can be configured.
1.00
Expert
DFNC
Off Off The selected Counter is Disabled.
Active Active The selected Counter is Enabled.
Counter Status counterStatus Returns the current state of the counter. (RO)
1.00
Expert
DFNC
Counter Idle CounterIdle The counter is idle.
The CounterStartSource feature is set to off.
Counter Trigger Wait CounterTriggerWait The counter is waiting for a start trigger.
Counter Active CounterActive The counter is counting for the specified duration.
Counter Completed CounterCompleted The counter reached the CounterDuration count.
Counter Overflow CounterOverflow The counter reached its maximum possible count.
Counter Start Source counterStartSource Select the counter start source. Counter
increments from 0 to the value of the
counterDuration feature.
1.10
Expert
DFNC
Off Off Counter is stopped.
Acquisition Start AcquisitionStart Counter starts on the reception of the Acquisition
Start event.
Exposure Start ExposureStart Counter starts on the reception of the Exposure
Start event.
Exposure End ExposureEnd Counter starts on the reception of the Exposure
End event.
Frame Start FrameStart Counter starts on the reception of the Frame Start
event.
Rejected Trigger InvalidTrigger Counter starts on the reception of the Invalid
Trigger.
Line 1 Line1 Counter starts on the specified transitions on Line
1.
Line 2 Line2 Counter starts on the specified transitions on Line
2.
Timer 1 End Timer1End Counter starts on the reception of the Timer 1 End
event.
Counter 1 End Counter1End Counter starts on the reception of the Counter 1
End event.
Counter Start Line
Activation
counterStartLineActivation Select the activation mode of the input line trigger
which starts the counter. This is only applicable
when the counterStartSource feature selects a
physical Line.
1.00
Expert
DFNC
