Dalsa Linea SWIR GigE Series User Manual

52
•
Operational Reference Linea SWIR GigE Series Camera
Display Name Feature & Values Description Device Version
& View
Defective Pixel
Replacement Mode
defectivePixelReplacementMode Sets the mode for the defective pixel
replacement.
1.00
Expert
DFNC
Off Off Defective Pixel Replacement is disabled.
Active Active Defective Pixel Replacement is enabled.
Defective Pixel
Replacement Map
Current Active Set
defectivePixelReplacementMapCurren
tActiveSet
Sets the defective pixel replacement set.
1.00
Expert
DFNC
Factory Map FactoryMap Sets the factory coefficient table as active.
User Map 1 UserMap1 Sets the User Map coefficient table as active.
Defective Pixel
Replacement Algorithm
defectivePixelReplacementAlgorithm Specifies the defective pixel replacement
algorithm.
1.00
Expert
DFNC
Method 1: Average Two
Adjacent Pixels
Method1 This algorithm replaces a defective pixel with the
average value of the pixel to the left and right of
the pixel to be replaced.
Method 3: Neighboring
Pixel
Method3 This algorithm replaces a defective pixel with a
neighbor.
Flat Field Correction
Mode
flatfieldCorrectionMode Sets the mode for the Flat Field correction. 1.00
Beginner
DFNC
Off Off Flat Field Correction is disabled.
Active Active Flat Field Correction is enabled.
Calibration Calibration When selected, the camera is configured for flat
field correction calibration. The device may
automatically adjust some of its features when
calibrate mode is enabled. The features that are
automatically adjusted are device specific. The
device will not restore these features when the
Flat Field Correction Mode feature is changed
from Calibrate mode to another mode.
Flat Field Correction
Current Active Set
flatfieldCorrectionCurrentActiveSet Specifies the current set of Flat Field coefficients
to use.
1.00
Beginner
DFNC
Factory Flatfield FactoryFlatfield Sets the factory Flat Field coefficient table as the
current Flat Field.
User Flatfield 1 UserFlatfield1 Sets User Flat Field 1 coefficient table as the
current Flat Field.
User Flatfield 2 UserFlatfield2 Sets User Flat Field 2 coefficient table as the
current Flat Field.
User Flatfield 3 UserFlatfield3 Sets User Flat Field 3 coefficient table as the
current Flat Field.
User Flatfield 4 UserFlatfield4 Sets User Flat Field 4 coefficient table as the
current Flat Field.
Flat Field Correction
Type
flatfieldCorrectionType Specifies the Flat Field correction type. 1.00
Guru
DFNC
Line-Based LineBase Flat Feld correction is based on an individual line
(FlatLine).
Flat Field Correction
Algorithm
flatfieldCorrectionAlgorithm Specifies the Flat Field correction algorithm to
use.
1.00
Guru
DFNC
Method 1 Method1 The following formula is used to calculate the
Flat Field corrected pixel: newPixelValue[x] =
(sensorPixelValue[x] - FFCOffset[x]) *
FFCGain[x]
Calibration Algorithm flatfieldCorrectionCalibrationAlgorith
m
Specifies the Flat Field calibration algorithm to
use.
1.00
Guru
DFNC
Basic Basic Direct calculation of coefficients based on
average line values and target.
