Operational Reference Linea SWIR GigE Series Camera

Features that cannot be changed during a Sapera Transfer

The following features cannot be changed during an acquisition or Sapera transfer.

Feature Group Features Locked During a Sapera Transfer

CAMERA INFORMATION UserSetLoad

SENSOR CONTROL NA

I/O CONTROL NA

COUNTER AND TIMER CONTROL NA

ADVANCED PROCESSING CONTROL flatfieldCorrectionMode

IMAGE FORMAT CONTROL PixelFormat

OffsetX

OffsetY

Width

Height

BinningHorizontal

BinningVertical

ACQUISITION AND TRANSFER CONTROL DeviceRegistersStreamingStart

DeviceRegistersStreamingEnd

EVENT CONTROL NA

GIGE VISION TRANSPORT LAYER CONTROL GevSCPSPacketSize

GIGE VISION HOST CONTROL InterPacketTimeout

InterPacketTimeoutRaw

ImageTimeout

FILE ACCESS CONTROL NA
