Danfoss FC 300

5-63 Terminal 29 Pulse Output Variable
Option: Function:
[0]
*
No operation Select the variable for viewing on the terminal 29 display. This
parameter is available for FC 302 only.
This parameter cannot be adjusted while the motor is running.
5-65 Pulse Output Maximum Frequency #29
Option: Function:
[5000H
z]
*
0 - 32000 Hz Set the maximum frequency for terminal 29 corresponding to
the output variable set in par. 5-63.
This parameter cannot be adjusted while the motor is running.
5-66 Terminal X30/6 Pulse Output Variable
Option: Function:
[0]
*
No operation Select the variable for read-out on terminal X30/6. This param-
eter cannot be adjusted while the motor is running.
This parameter is active when option module MCB 101 is instal-
led in the frequency converter.
5-68 Pulse Output Maximum Frequency #X30/6
Range: Function:
5000Hz
*
[0 - 32000 Hz] Select the maximum frequency on terminal X30/6 referring to
the output variable in par. 5-66. This parameter cannot be ad-
justed while the motor is running.
This parameter is active when option module MCB 101 is moun-
ted in the frequency converter.
2.8.8. 5-7* 24 V Encoder Input
Parameters for configuring the 24 V encoder.
Connect the 24 V encoder to terminal 12 (24 V DC supply), terminal 32 (Channel A), terminal 33
(Channel B), and terminal 20 (GND). The digital inputs 32/33 are active for encoder inputs when
24 V encoder is selected in par. 1-02 and par. 7-00. The encoder used is a dual channel (A and
B) 24 V type. Max input frequency: 110 kHz.
