[2] Forced stop, ref = 0 Resets the local reference to 0 upon restarting the frequency
converter.
2.3.3. 0-1* Set-up Operations
Define and control the individual parameter setups.
The frequency converter has four parameter setups that can be programmed independently of
each other. This makes the frequency converter very flexible and able to solve advanced control
functionality problems, often saving the cost of external control equipment. For example these
can be used to program the frequency converter to operate according to one control scheme in
one setup (e.g. motor 1 for horizontal movement) and another control scheme in another setup
(e.g. motor 2 for vertical movement). Alternatively they can be used by an OEM machine builder
to identically program all their factory fitted frequency converters for different machine types
within a range to have the same parameters and then during production/commissioning simply
select a specific setup depending on which machine the frequency converter is installed on.
The active setup (i.e. the setup in which the frequency converter is currently operating) can be
selected in parameter 0-10 and is displayed in the LCP. Using Multi set-up it is possible to switch
between setups with the frequency converter running or stopped, via digital input or serial com-
munication commands. If it is necessary to change setups whilst running, ensure parameter 0-12
is programmed as required. Using parameter 0-11 it is possible to edit parameters within any of
the setups whilst continuing the frequency converter operation in its Active Setup which can be a
different setup to that being edited. Using parameter 0-51 it is possible to copy parameter settings
between the setups to enable quicker commissioning if similar parameter settings are required in
different setups.
0-10 Active Set-up
Option: Function:
Select the set-up to control the frequency converter functions.
[0] Factory setup Cannot be changed. It contains the Danfoss data set, and can
be used as a data source when returning the other set-ups to a
known state.
[1]
*
Set-up 1
Set-up 1
[1] to
Set-up 4
[4] are the four separate parameter
set-ups within which all parameters can be programmed.
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Multi set-up Remote selection of set-ups using digital inputs and the serial
communication port. This set-up uses the settings from par.
0-12 'This option linked to'. Stop the frequency converter before
making changes to open- and closed loop functions
Use par. 0-51
Set-up copy
to copy a set-up to one or all other set-ups. Stop the frequency con-
verter before switching between set-ups where parameters marked ‘not changeable during
operation’ have different values. To avoid conflicting settings of the same parameter within two
different set-ups, link the set-ups together using par. 0-12
This set-up linked to
. Parameters which
are ‘not changeable during operation’ are marked FALSE in the parameter lists in the section
Parameter Lists
.
FC 300 Programming Guide 2. How to Programme
MG.33.M2.02 - VLT
®
is a registered Danfoss trademark
29
