Danfoss VLT 6000 HVAC Series User Manual

Activation/deactivation can be programmed in param-
eter 324 Relay 1, ON delay and parameter 325 Relay 1,
OFF delay.
See General technical data.
Description of choice:
See data choice and connections in Relay outputs.
324 Relay 01, ON delay
(RELAY1 ON DELAY)
Value:
0 - 600 sec.
0 sec.
Function:
This parameter allows a delay of the cut-in time of relay
1 (terminals 1-2).
Description of choice:
Enter the desired value.
325 Relay 01, OFF delay
(RELAY1 OFF DELAY)
Value:
0 - 600 sec.
0 sec.
Function:
This parameter makes it possible to delay the cut-out
time of relay 01 (terminals 1-2).
Description of choice:
Enter the desired value.
326 Relay 2, output function
(RELAY2 FUNCTION)
Value:
See functions of relay 2 on previous page.
Function:
This output activates a relay switch. Relay switch 2 can
be used for indicating status and warnings. The relay
is activated when the conditions for the relevant data
values have been fulfilled.
See General technical data.
Description of choice:
See data choice and connections in Relay outputs.
327 Pulse reference, max. frequency
(PULSE REF. MAX)
Value:
100 - 65000 Hz at terminal 29
5000 Hz
100 - 5000 Hz at terminal 17
Function:
This parameter is used to set the pulse value that must
correspond to the maximum reference, parameter 205
Maximum reference, Ref
MAX
.
The pulse reference signal can be connected via ter-
minal 17 or 29.
Description of choice:
Set the required maximum pulse reference.
328 Pulse feedback, max. frequency
(PULSE FDBK MAX.)
Value:
100 - 65000 Hz at terminal 33
25000 Hz
Function:
This is where the pulse value that must correspond to
the maximum feedback value is set. The pulse fedback
signal is connected via terminal 33.
Description of choice:
Set the desired feedback value.
364 Terminal 42, bus control
(CONTROL OUTPUT 42)
365 Terminal 45, bus control
(CONTROL OUTPUT 45)
Value:
VLT
®
6000 HVAC Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
MG.61.B5.02 - VLT
®
is a registered Danfoss trademark 137
Programming
