Danfoss VLT 6000 HVAC Series User Manual

WEDNESDAY [3]
THURSDAY [4]
FRIDAY [5]
SATURDAY [6]
SUNDAY [7]
ANY DAY [8]
MONDAY TO FRIDAY [9]
SAT. AND SUNDAY [10]
MONDAY TO THURS. [11]
FRIDAY TO SUNDAY [12]
SUNDAY TO FRIDAY [13]
Function:
Set the weekday for specific actions to be executed.
Description of choice:
The selection of weekday is used to determine the
weekday an action must be executed.
783 ON clock
(ON CLOCK)
Value:
[Index 00 - 20] 00.00 - 23.59
00.00
Function:
The ON Clock entry defines at which time of the day
the corresponding ON Action will take place.
Description of choice:
Enter the time at which the ON action should take
place.
784 ON action
(ON ACTION)
Value:
NO ACTION DEFINED [0]
SETUP 1 [1]
SETUP 2 [2]
SETUP 3 [3]
SETUP 4 [4]
PRESET REF. 1 [5]
PRESET REF. 2 [6]
PRESET REF. 3 [7]
PRESET REF. 4 [8]
AO42 OFF [9]
AO42 ON [10]
AO45 OFF [11]
AO45 ON [12]
RELAY 1 ON [13]
RELAY 1 OFF [14]
RELAY 2 ON [15]
RELAY 2 OFF [16]
START DRIVE [17]
STOP DRIVE [18]
Function:
An action to be executed is selected here.
Description of choice:
When the time in parameter 782 is passed the action
in the corresponding index is executed. Setup 1 to 4
[1] – [4] is simply selecting setups. The RTC overrules
setup selection via digital inputs and bus input. Preset
ref [5] – [8] is selecting preset reference. The RTC
overrules preset ref selection via digital inputs and bus
input. AO42 and AO45 and Relay 1 and 2 [9] – [16]
simply activate or deactivate the outputs. Start drive
[17] starts the frequency converter, the command is
AND’ed or OR’ed with the digital input commands and
the bus command. This, however, depends on the se-
lection in parameter 505. Stop drive [18] just stops the
frequency converter again.
785 OFF clock
(OFF CLOCK)
Value:
[Index 00 - 20] 00.00 - 23.59
00.00
Function:
The OFF Clock entry defines at which time of the day
the corresponding OFF Action will take place.
Description of choice:
Enter the time at which the OFF action should take
place.
786 OFF action
(OFF ACTION)
Value:
NO ACTION DEFINED [0]
SETUP 1 [1]
SETUP 2 [2]
SETUP 3 [3]
SETUP 4 [4]
PRESET REF. 1 [5]
VLT
®
6000 HVAC Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
MG.61.B5.02 - VLT
®
is a registered Danfoss trademark 183
Programming
