Danfoss VLT AHF 005

600 V
60 Hz
AHF 005
IP00
AHF 005
IP20
Current
rating
Dimensions Weight
Enclosure
size
Dimensions Weight Enclosure size
[A]
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP00
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP20
15 590 (23.2) 378 (14.9) 245 (9.6) 35 (77) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 42 (93) X3 IP20 if1
20 590 (23.2) 378 (14.9) 245 (9.6) 43 (95) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 50 (110) X3 IP20 if1
24 634 (25) 378 (14.9) 333 (13.1) 44 (97) X3 IP00 615 (24.2) 378 (14.9) 245 (9.6) 52 (115) X3 IP20 ef1
29 620 (24.4) 378 (14.9) 338 (13.3) 67 (148) X4 IP00 644 (25.4) 378 (14.9) 338 (13.3) 75 (165) X4 IP20 ef1
36 620 (24.4) 378 (14.9) 338 (13.3) 74 (164) X4 IP00 644 (25.4) 378 (14.9) 338 (13.3) 82 (181) X4 IP20 ef1
50 737 (29) 418 (16.5) 333 (13.1) 86 (190) X5 IP00 775 (30.5) 418 (16.5) 333 (13.1) 96 (212) X5 IP20 ef1
58 737 (29) 418 (16.5) 333 (13.1) 94 (207) X5 IP00 775 (30.5) 418 (16.5) 333 (13.1) 104 (229) X5 IP20 ef1
77 767 (30.2) 418 (16.5) 405 (15.9) 117 (258) X6 IP00 789 (31) 418 (16.5) 405 (15.9) 130 (287) X6 IP20 ef1
87 767 (30.2) 418 (16.5) 405 (15.9) 122 (269) X6 IP00 789 (31) 418 (16.5) 405 (15.9) 135 (298) X6 IP20 ef1
109 767 (30.2) 418 (16.5) 405 (15.9) 155 (342) X6 IP00 789 (31) 418 (16.5) 405 (15.9) 168 (370) X6 IP20 ef1
128 767 (30.2) 418 (16.5) 405 (15.9) 184 (406) X6 IP00 789 (31) 418 (16.5) 405 (15.9) 197 (434) X6 IP20 ef1
155 949 (37.4) 468 (18.4) 451 (17.8) 203 (448) X7 IP00 966 (38) 468 (18.4) 451 (17.8) 220 (485) X7 IP20 ef1
197 949 (37.4) 468 (18.4) 451 (17.8) 209 (461) X7 IP00 966 (38) 468 (18.4) 451 (17.8) 228 (503) X7 IP20 ef1
240 949 (37.4) 468 (18.4) 515 (20.3) 241 (531) X8 IP00 966 (38) 468 (18.4) 515 (20.3) 260 (573) X8 IP20 ef1
296 949 (37.4) 468 (18.4) 515 (20.3) 278 (613) X8 IP00 966 (38) 468 (18.4) 515 (20.3) 297 (655) X8 IP20 ef1
366 – – – – – – – – – –
395 – – – – – – – – – –
Table 7.15 600 V, 60 Hz, AHF 005
600 V
60 Hz
AHF 010
IP00
AHF 010
IP20
Current
rating
Dimensions Weight
Enclosure
size
Dimensions Weight Enclosure size
[A]
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP00
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP20
15 590 (23.2) 378 (14.9) 245 (9.6) 18 (40) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 25 (55) X3 IP20 if1
20 590 (23.2) 378 (14.9) 245 (9.6) 29 (64) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 36 (79) X3 IP20 if1
24 634 (25) 378 (14.9) 333 (13.1) 32 (71) X3 IP00 615 (24.2) 378 (14.9) 245 (9.6) 40 (88) X3 IP20 ef1
29 620 (24.4) 378 (14.9) 338 (13.3) 34 (75) X4 IP00 644 (25.4) 378 (14.9) 338 (13.3) 42 (93) X4 IP20 ef1
36 620 (24.4) 378 (14.9) 338 (13.3) 44 (97) X4 IP00 644 (25.4) 378 (14.9) 338 (13.3) 52 (115) X4 IP20 ef1
50 737 (29) 418 (16.5) 333 (13.1) 46 (101) X5 IP00 775 (30.5) 418 (16.5) 333 (13.1) 56 (123) X5 IP20 ef1
58 737 (29) 418 (16.5) 333 (13.1) 52 (115) X5 IP00 775 (30.5) 418 (16.5) 333 (13.1) 62 (137) X5 IP20 ef1
77 767 (30.2) 418 (16.5) 405 (15.9) 61 (134) X6 IP00 789 (31) 418 (16.5) 405 (15.9) 74 (163) X6 IP20 ef1
87 767 (30.2) 418 (16.5) 405 (15.9) 72 (159) X6 IP00 789 (31) 418 (16.5) 405 (15.9) 85 (187) X6 IP20 ef1
109 767 (30.2) 418 (16.5) 405 (15.9) 92 (203) X6 IP00 789 (31) 418 (16.5) 405 (15.9) 105 (231) X6 IP20 ef1
128 767 (30.2) 418 (16.5) 405 (15.9) 110 (243) X6 IP00 789 (31) 418 (16.5) 405 (15.9) 123 (271) X6 IP20 ef1
155 949 (37.4) 468 (18.4) 451 (17.8) 119 (262) X7 IP00 966 (38) 468 (18.4) 451 (17.8) 136 (300) X7 IP20 ef1
197 949 (37.4) 468 (18.4) 451 (17.8) 125 (276) X7 IP00 966 (38) 468 (18.4) 451 (17.8) 142 (313) X7 IP20 ef1
240 949 (37.4) 468 (18.4) 451 (17.8) 144 (317) X7 IP00 966 (38) 468 (18.4) 451 (17.8) 163 (359) X7 IP20 ef1
296 949 (37.4) 468 (18.4) 515 (20.3) 186 (410) X8 IP00 966 (38) 468 (18.4) 515 (20.3) 205 (452) X8 IP20 ef1
366 949 (37.4) 468 (18.4) 515 (20.3) 209 (461) X8 IP00 966 (38) 468 (18.4) 515 (20.3) 228 (503) X8 IP20 ef1
395 949 (37.4) 468 (18.4) 515 (20.3) 241 (531) X8 IP00 966 (38) 468 (18.4) 515 (20.3) 260 (573) X8 IP20 ef1
Table 7.16 600 V, 60 Hz, AHF 010
Specications
VLT
®
Advanced Harmonic Filter AHF 005/AHF 010
