Danfoss VLT AHF 005

500–690 V
50 Hz
AHF 005
IP00
AHF 005
IP20
Current
rating
Dimensions Weight
Enclosure
size
Dimensions Weight Enclosure size
[A]
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP00
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP20
15 590 (23.2) 378 (14.9) 245 (9.6) 35 (77) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 42 (93) X3 IP20 if2
20 590 (23.2) 378 (14.9) 245 (9.6) 43 (95) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 50 (110) X3 IP20 if2
24 634 (25) 378 (14.9) 333 (13.1) 44 (97) X3 IP00 629 (24.8) 378 (14.9) 245 (9.6) 52 (115) X3 IP20 ef2
29 620 (24.4) 378 (14.9) 338 (13.3) 67 (148) X4 IP00 658 (25.9) 378 (14.9) 338 (13.3) 75 (165) X4 IP20 ef2
36 620 (24.4) 378 (14.9) 338 (13.3) 74 (164) X4 IP00 658 (25.9) 378 (14.9) 338 (13.3) 82 (181) X4 IP20 ef2
50 737 (29) 418 (16.5) 333 (13.1) 86 (190) X5 IP00 775 (30.5) 418 (16.5) 333 (13.1) 96 (212) X5 IP20 ef2
58 737 (29) 418 (16.5) 333 (13.1) 94 (207) X5 IP00 775 (30.5) 418 (16.5) 333 (13.1) 104 (229) X5 IP20 ef2
77 767 (30.2) 418 (16.5) 405 (15.9) 117 (258) X6 IP00 806 (31.7) 418 (16.5) 405 (15.9) 130 (287) X6 IP20 ef2
87 767 (30.2) 418 (16.5) 405 (15.9) 122 (269) X6 IP00 806 (31.7) 418 (16.5) 405 (15.9) 135 (298) X6 IP20 ef2
109 767 (30.2) 418 (16.5) 405 (15.9) 155 (342) X6 IP00 806 (31.7) 418 (16.5) 405 (15.9) 168 (370) X6 IP20 ef2
128 767 (30.2) 418 (16.5) 405 (15.9) 184 (406) X6 IP00 806 (31.7) 418 (16.5) 405 (15.9) 197 (434) X6 IP20 ef2
155 949 (37.4) 468 (18.4) 451 (17.8) 203 (448) X7 IP00 989 (38.9) 468 (18.4) 451 (17.8) 220 (485) X7 IP20 ef2
197 949 (37.4) 468 (18.4) 451 (17.8) 209 (461) X7 IP00 989 (38.9) 468 (18.4) 451 (17.8) 228 (503) X7 IP20 ef2
240 949 (37.4) 468 (18.4) 515 (20.3) 241 (531) X8 IP00 989 (38.9) 468 (18.4) 515 (20.3) 260(573) X8 IP20 ef2
296 949 (37.4) 468 (18.4) 515 (20.3) 278 (613) X8 IP00 989 (38.9) 468 (18.4) 515 (20.3) 297 (655) X8 IP20 ef2
366 – – – – – – – – – –
395 – – – – – – – – – –
Table 7.17 500–690 V, 50 Hz, AHF 005
500–690 V
50 Hz
AHF 010
IP00
AHF 010
IP20
Current
rating
Dimensions Weight
Enclosure
size
Dimensions Weight Enclosure size
[A]
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP00
Height
[mm (in)]
Width
[mm (in)]
Depth
[mm (in)]
[kg (lb)] IP20
15 590 (23.2) 378 (14.9) 245 (9.6) 18 (40) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 25 (55) X3 IP20 if2
20 590 (23.2) 378 (14.9) 245 (9.6) 29 (64) X3 IP00 590 (23.2) 378 (14.9) 245 (9.6) 36 (79) X3 IP20 if2
24 634 (25) 378 (14.9) 333 (13.1) 32 (71) X3 IP00 629 (24.8) 378 (14.9) 245 (9.6) 40 (88) X3 IP20 ef2
29 620 (24.4) 378 (14.9) 338 (13.3) 34 (75) X4 IP00 658 (25.9) 378 (14.9) 338 (13.3) 42 (93) X4 IP20 ef2
36 620 (24.4) 378 (14.9) 338 (13.3) 44 (97) X4 IP00 658 (25.9) 378 (14.9) 338 (13.3) 52 (115) X4 IP20 ef2
50 737 (29) 418 (16.5) 333 (13.1) 46 (101) X5 IP00 775 (30.5) 418 (16.5) 333 (13.1) 56 (123) X5 IP20 ef2
58 737 (29) 418 (16.5) 333 (13.1) 52 (115) X5 IP00 775 (30.5) 418 (16.5) 333 (13.1) 62 (137) X5 IP20 ef2
77 767 (30.2) 418 (16.5) 405 (15.9) 61 (134) X6 IP00 806 (31.7) 418 (16.5) 405 (15.9) 74 (163) X6 IP20 ef2
87 767 (30.2) 418 (16.5) 405 (15.9) 72 (159) X6 IP00 806 (31.7) 418 (16.5) 405 (15.9) 85 (187) X6 IP20 ef2
109 767 (30.2) 418 (16.5) 405 (15.9) 92 (203) X6 IP00 806 (31.7) 418 (16.5) 405 (15.9) 105 (231) X6 IP20 ef2
128 767 (30.2) 418 (16.5) 405 (15.9) 110 (243) X6 IP00 806 (31.7) 418 (16.5) 405 (15.9) 123 (271) X6 IP20 ef2
155 949 (37.4) 468 (18.4) 451 (17.8) 119 (262) X7 IP00 989 (38.9) 468 (18.4) 451 (17.8) 136 (300) X7 IP20 ef2
197 949 (37.4) 468 (18.4) 451 (17.8) 125 (276) X7 IP00 989 (38.9) 468 (18.4) 451 (17.8) 142 (313) X7 IP20 ef2
240 949 (37.4) 468 (18.4) 451 (17.8) 144 (317) X7 IP00 989 (38.9) 468 (18.4) 451 (17.8) 163 (359) X7 IP20 ef2
296 949 (37.4) 468 (18.4) 515 (20.3) 186 (410) X8 IP00 989 (38.9) 468 (18.4) 515 (20.3) 205 (452) X8 IP20 ef2
366 949 (37.4) 468 (18.4) 515 (20.3) 209 (461) X8 IP00 989 (38.9) 468 (18.4) 515 (20.3) 228 (503) X8 IP20 ef2
395 949 (37.4) 468 (18.4) 515 (20.3) 241 (531) X8 IP00 989 (38.9) 468 (18.4) 515 (20.3) 260 (573) X8 IP20 ef2
Table 7.18 500–690 V, 50 Hz, AHF 010
