Danfoss VLT AHF 005

Filter
current
rating
Maximum
fuse size
Fuses
1)
[A] [A] (type)
15 35
Class J, 600 V AC, rated breaking
capacity 100 kA
20 35
Class J, 600 V AC, rated breaking
capacity 100 kA
24 50
Class J, 600 V AC, rated breaking
capacity 100 kA
29 50
Class J, 600 V AC, rated breaking
capacity 100 kA
36 60
Class J, 600 V AC, rated breaking
capacity 100 kA
50 80
Class J, 600 V AC, rated breaking
capacity 100 kA
58 100
Class J, 600 V AC, rated breaking
capacity 100 kA
77 125
Class J, 600 V AC, rated breaking
capacity 100 kA
87 150
Class J, 600 V AC, rated breaking
capacity 100 kA
109 200
Class J, 600 V AC, rated breaking
capacity 100 kA
128 250
Class J, 600 V AC, rated breaking
capacity 100 kA
155 300
Class J, 600 V AC, rated breaking
capacity 100 kA
197 350
Class J, 600 V AC, rated breaking
capacity 100 kA
240 400
Class J, 600 V AC, rated breaking
capacity 100 kA
296 500
Class J, 600 V AC, rated breaking
capacity 100 kA
366 600
Class J, 600 V AC, rated breaking
capacity 100 kA
395 600
Class J, 600 V AC, rated breaking
capacity 100 kA
Table 7.23 600 V, 60 Hz
1)
Specied type is a UL requirement.
Filter
current
rating
Maximum
fuse size
Fuses
[A] [A] (type)
15 35 gRL 690 V AC
20 35 gRL 690 V AC
24 50 gRL 690 V AC
29 50 gRL 690 V AC
36 63 gRL 690 V AC
50 80 gRL 690 V AC
58 125 gRL 690 V AC
77 160 gRL 690 V AC
87 250 gRL 690 V AC
109 250 gRL 690 V AC
128 250 gRL 690 V AC
155 315 gRL 690 V AC
197 350 gRL 690 V AC
240 400 gRL 690 V AC
296 500 gRL 690 V AC
366 630 gRL 690 V AC
395 630 gRL 690 V AC
Table 7.24 500–690 V, 50 Hz
In applications where lters are paralleled, it might be
necessary to install fuses in front of each lter and in front
of the frequency converter.
