600 V
60 Hz
Terminals X1+X2 Terminals X3+X4 Terminals A+B
Current
rating
Ordering
number
Description
Ordering
number
Description
Ordering
number
Description
[A]
[Mains input and output
terminals]
[Capacitor disconnect
terminals]
[Thermal switch
terminals]
15 175U0260 WDU 16 600 V 85 A 175U0259 WDU 10 600 V 65 A 175U0257 WDU 2.5 600 V 25 A
20 175U0260 WDU 16 600 V 85 A 175U0259 WDU 10 600 V 65 A 175U0257 WDU 2.5 600 V 25 A
24 175U0261 WDU 35 1000 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
29 175U0261 WDU 35 1000 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
36 175U0261 WDU 35 1000 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
50 175U0262 WDU 50N 600 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
58 175U0262 WDU 50N 600 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
77 175U0263 WFF70N/AH 1000 V 183 A 175U0261 WDU 35 1000 V 150 A 175U0257 WDU 2.5 600 V 25 A
87 175U0263 WFF70N/AH 1000 V 183 A 175U0261 WDU 35 1000 V 150 A 175U0257 WDU 2.5 600 V 25 A
109 175U0263 WFF70N/AH 1000 V 183 A 175U0261 WDU 35 1000 V 150 A 175U0257 WDU 2.5 600 V 25 A
128 175U0263 WFF70N/AH 1000 V 183 A 175U0261 WDU 35 1000 V 150 A 175U0257 WDU 2.5 600 V 25 A
155 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
197 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
240 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
296 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
366 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
395 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
Table 8.9 Terminal Kits, 600 V 60 Hz
500–690 V
50 Hz
Terminals X1+X2 Terminals X3+X4 Terminals A+B
Current
rating
Ordering
number
Description
Ordering
number
Description
Ordering
number
Description
[A]
[Mains input and output
terminals]
[Capacitor disconnect
terminals]
[Thermal switch
terminals]
15 175U0260 WDU 16 600 V 85 A 175U0259 WDU 10 600 V 65 A 175U0257 WDU 2.5 600 V 25 A
20 175U0260 WDU 16 600 V 85 A 175U0259 WDU 10 600 V 65 A 175U0257 WDU 2.5 600 V 25 A
24 175U0261 WDU 35 1000 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
29 175U0261 WDU 35 1000 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
36 175U0261 WDU 35 1000 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
50 175U0262 WDU 50N 600 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
58 175U0262 WDU 50N 600 V 150 A 175U0260 WDU 16 600 V 85 A 175U0257 WDU 2.5 600 V 25 A
77 175U0263 WFF70N/AH 1000 V 183 A 175U0261 WDU 35 1000 V 150 A 175U0257 WDU 2.5 600 V 25 A
87 175U0263 WFF70N/AH 1000 V 183 A 175U0261 WDU 35 1000 V 150 A 175U0257 WDU 2.5 600 V 25 A
109 175U0263 WFF70N/AH 1000 V 183 A 175U0261 WDU 35 1000 V 150 A 175U0257 WDU 2.5 600 V 25 A
128 175U0263 WFF70N/AH 1000 V 183 A 175U0261 WDU 35 1000 V 150 A 175U0257 WDU 2.5 600 V 25 A
155 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
197 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
240 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
296 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
366 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
395 175U0265 WFF300/AH 1000 V 500 A 175U0264 WDU 95N 1000 V 228 A 175U0257 WDU 2.5 600 V 25 A
Table 8.10 Terminal Kits, 500–690 V 50 Hz
Spare Parts Design Guide
MG80C502 Danfoss A/S © 10/2016 All rights reserved. 139
