Danfoss VLT AHF 005

Selection table, 380–415 V, 60 Hz
Frequency converter values Filter values
Power
rating
Input current
Current
rating
Ordering numbers Power loss
Acoustic
noise
Enclosure sizes, enclosure protection ratings, and fan
concept
T4/T5 380–440 V AHF 005 AHF 010 AHF 005 AHF 010 AHF 005 AHF 010
[kW]
1)
[A] [A] IP00 IP20 IP00 IP20 [W] [W] [dB(A)] IP00 IP20 IP00 IP20
0.37 1.2
10 130B3095 130B2857 130B2874 130B2262 131 93 <70 X1 IP00 X1 IP20 if1 X1 IP00 X1 IP20 if1
0.55 1.6 0.75 2.2
1.1 2.7 1.5 3.7 2.2 5.0 3.0 6.5 4.0 9.0 5.5 11.7
14 130B3096 130B2858 130B2875 130B2265 184 118 <70 X1 IP00 X1 IP20 ef1 X1 IP00 X1 IP20 ef1
7.5 14.4
11 22 22 130B3097 130B2859 130B2876 130B2268 258 206 <70 X2 IP00 X2 IP20 ef1 X2 IP00 X2 IP20 if1
15 29 29 130B3098 130B2860 130B2877 130B2294 298 224 <70 X2 IP00 X2 IP20 ef1 X2 IP00 X2 IP20 if1
18.5 34 34 130B3099 130B2861 130B3000 130B2297 335 233 <72 X3 IP00 X3 IP20 if1 X3 IP00 X3 IP20 if1
22 40 40 130B3124 130B2862 130B3083 130B2303 396 242 <72 X3 IP00 X3 IP20 if1 X3 IP00 X3 IP20 if1 30 55 55 130B3125 130B2863 130B3084 130B2445 482 274 <72 X3 IP00 X3 IP20 if1 X3 IP00 X3 IP20 if1 37 66 66 130B3126 130B2864 130B3085 130B2459 574 352 <72 X4 IP00 X4 IP20 if1 X4 IP00 X4 IP20 if1 45 82 82 130B3127 130B2865 130B3086 130B2488 688 374 <72 X4 IP00 X4 IP20 ef1 X4 IP00 X4 IP20 ef1 55 96 96 130B3128 130B2866 130B3087 130B2489 747 428 <75 X5 IP00 X5 IP20 ef1 X5 IP00 X5 IP20 ef1 75 133 133 130B3129 130B2867 130B3088 130B2498 841 488 <75 X5 IP00 X5 IP20 ef1 X5 IP00 X5 IP20 ef1 90 171 171 130B3130 130B2868 130B3089 130B2499 962 692 <75 X6 IP00 X6 IP20 ef1 X6 IP00 X6 IP20 if1
110 204 204 130B3131 130B2869 130B3090 130B2500 1080 743 <75 X6 IP00 X6 IP20 ef1 X6 IP00 X6 IP20 if1 132 251 251 130B3132 130B2870 130B3091 130B2700 1194 864 <75 X7 IP00 X7 IP20 if1 X7 IP00 X7 IP20 if1 160 304 304 130B3133 130B2871 130B3092 130B2819 1288 905 <75 X8 IP00 X8 IP20 if1 X7 IP00 X7 IP20 if1
– – 325
130B3157
2)
130B3156
2)
130B3155
2)
130B3154
2)
1406 952 <75 X8 IP00 X8 IP20 if1 X7 IP00 X7 IP20 if1
200 381 381 130B3134 130B2872 130B3093 130B2855 1510 1175 <77 X8 IP00 X8 IP20 ef1 X7 IP00 X7 IP20 if1 250 463 480 130B3135 130B2873 130B3094 130B2856 1852 1542 <77 X8 IP00 X8 IP20 ef1 X8 IP00 X8 IP20 ef1
Selection of Advanced Harmo...
