Danfoss VLT AHF 005

130BB598.11
248 ± 2.5 mm [9.7± 0.1 in]
205 ± 1 mm [8.1 ± 0.04 in] 230 ± 1 mm [9.1 ± 0.04 in]
X1 Mains 10mm
2
A/B Temperature 2.5mm
2
X2 Drive 10mm
2
X3/X4 Capacitor disconnect 2.5mm
2
PE M6
F1
F2
350 ± 2 mm [13.8 ± 0.1 in]
382 ± 2.5 mm [15.0 ± 0.1 in]
399 ± 2.5 mm [15.7 ± 0.1 in]
421 ± 2.5 mm [16.6 ± 0.1 in]
455 ± 2.5 mm [17.9 ± 0.1 in]
45 ± 2 mm [1.8 ± 0.08 in]
6.5 ± 1 mm [0.3 ± 0.04 in]
238 ± 2 mm [9.4 ± 0.1 in]
232 ± 2 mm [9.1 ± 0.1 in]
Illustration 7.11 IP20 X2 External Fan 1
130BE370.10
Illustration 7.12 IP20 X2 External Fan 1, 3D View
Specications Design Guide
MG80C502 Danfoss A/S © 10/2016 All rights reserved. 63
7 7
