Danfoss VLT AHF 005 - Page 66

130BB595.11
F1
F2
PE M8
245 ± 2.5 mm [9.6 ± 0.1 in]
353 ± 2.5 mm [13.9 ± 0.1 in] 378 ± 2.5 mm [14.9 ± 0.1 in]
X1 Mains 16mm
2
A/B Temperature 2.5mm
2
X2 Drive 16mm
2
X3/X4 Capacitor disconnect 10mm
2
460 ± 2.5 mm [18.1 ± 0.1 in]
9 ± 1 mm [0.4 ± 0.04 in]
9 ± 1 mm [0.4 ± 0.04 in]
547 ± 2.5 mm [21.5 ± 0.1 in]
550 ± 2.5 mm [21.6 ± 0.1 in]
590 ± 2.5 mm [23.2 ± 0.1 in]
145 ± 1 mm [5.7 ± 0.04 in] 145 ± 1 mm [5.7 ± 0.04 in]233 ± 1 mm [9.2 ± 0.04 in]
330 ± 2.5 mm [13.0 ± 0.1 in]
Illustration 7.13 IP20 X3 Internal Fan 1
130BE372.10
Illustration 7.14 IP20 X3 Internal Fan 1, 3D View
Specications
VLT
®
Advanced Harmonic Filter AHF 005/AHF 010
64 Danfoss A/S © 10/2016 All rights reserved. MG80C502
77
